Specification

Extend the height of your storage with the Garage+ extension standard. Possible to create a solution with a maximum height of 3324 mm. Seamlessly attach it to a  standard.
Product LineGarage+ by Elfa
Article number
440951
ColorMatte grey
Width (mm)25
Depth (mm)27
Height1148
<

Technical description

Special hang standard intended to fit below a hang standard, in order to join two standards. Combine with extension hang standard adapter.

Makes it possible to create 3324 mm (130-7/8”) high solutions:
Hang Standard 2172 mm (85-4/8”) + Extension hang standard adapter distance 4 mm (1/8”) + Extension hang standard 1148mm (45-2/8”)

Extension standards can be cut to size, in order to adapt them to the desired height. When adjusting the combined standards height, cut the extension standard.

Extension hang standards are made of high quality, epoxy-bonded steel. They have have two rows of slots, spaced 32 mm apart.

Colour:
Matte Grey (polyester colour) NCS S 7500-N, fine texture, gloss 5
<

Planning rules

When planning in Elfa Planner, the design tool will automatically add extension standard and extension standard adapter, when you are planning solution heights surpassing 2172 mm. The Elfa Planner will also take into account which slots that are unavailable to mount products in, where the the two  standards join, since the extension hang standard adapter prevents those slots to be used.

It is not possible to  have multiple extension standards.

The extension standard can be cut, as long as there are 4 slots from the top remaining on the extension hang standard. Always make the cut from the bottom of the extension hang standard.
<

Safety and care

Safety

Note! Do not place Elfa products in direct contact with water.

Care

Wipe clean with a cloth dampered with a mild cleaner. Wipe dry with a clean cloth.

<

Assembly Instructions

Assembly Instructions
Förlängningskena 1148mm matgry Förlängningshäng standardadapter Matt grå
Garage+ by Elfa

Extension standard 1148 mm Matte grey

Recommended price

45,60

Extend the height of your storage with the Garage+ extension standard. Possible to create a solution with a maximum height of 3324 mm. Seamlessly attach it to a  standard.

  • Expand your storage solution up to a height of 3324 mm
  • Tailor the system's height to fit your unique needs, optimizing space usage
  • Effortless assembly with Garage+ extension standard adapter
