You need the following to assemble: rubber hammer/mallet and something to protect the floor (carpet, piece of cardboard etc.). If you don’t have a rubber hammer/mallet, you can use a hammer with a wood block to protect the frame.

Before you start: Make sure to secure that you are working on a non-sensitive surface – for example on a carpet or use a wood block or a piece of cardboard under the frames to protect the floor when hammering.

Step 1: Start by turning the frame sides upside down and lining them up next to eachother. Secure that the “runners” (A), the U-shaped channels on the inside of the frames, are pointing inwards.

Step 2: Fasten the crossbars with “double teeth” (B) to the frame side, using the rubber hammer/mallet. The Elfa Logo on the crossbars will read upside down in this position.

Step 3: Turn the structure again.

Step 4: Fasten the remaining crossbars with the “single tooth” and a flat top (C).

When finished, attach casters or frame feet onto the bottom teeth (not included).

When mounting a drawer system on top of another drawer system, use the crossbar extension set (see separate assembly instruction under "Extension kit").

Finally, slide in drawers.
